Swing : 290 mm, Length Between Centres : 1000 mm

Maximum weight of work - piece : 60kg, Grinding Wheel (dia x W x Hole): 400 x 40

Diameter of Grinding Wheel after wear : 250mm, Swing in open rest: 70mm

Swing in enclosed rest : 70mm, Taper in work spindle : no 4 Morse

Taper in Tailstock sleeve: no.4 Morse, Diameter of chuck : 125mm

Hole in socket for internal grinding spindle: 80mm.  Speeds of wheel spindle :

Speeds of Work spindle (12 speeds): 710 - 2214 rpm

Hydraulic rapid Traverse of wheelhead : 40mm

Power infeed in table reversal (refers to diameter) : 0.005 to 0.03mm

Rate of power infeed for infeed grinding per minute (refers to diameter) 0.05 to

Swivel of Wheelhead (+,-) 45 Degree , Swivel of workhead (+, -)  90 Degree

Speed of table, infinitely variable, per minute: 0.05 to 7 metres
