Vertical Grinding Machine

Maker:               Doerriess

Type:                 VSE 125

Year of Manuf.:          1977

S/L No.

Specifications:

Max. swing                                                           1 400        mm

Table dia.                                                               1 250       mm

Max. grinding height                                             1 100       mm

Grinding heads inclination, left/right                    30/45       Deg.

Table Rotation                                                   2.8- 150       rpm

Stroke Tool Holder                                                620       mm

Feed, per Rotation                                           0.043 8       mm/r

Feed, per Min.                                             0.238 527       mm/min

Rapid feed                                                              1250       mm/min

Weight of the Machine approx.                                  25       to

Electrics                                                               380/50       V/Hz

          Accessories/Features:

-     2 Grinding Heads on Cross Rail
