Spindle:-
Diameter 3,937
Morse Taper No. 6
Tables:-
Dimensions of main rectangular table 47 1 / 4 x 7I
Dimensions of auxiliary square swivelling table for main rectangular table 47 1 / 4 x 47 1 / 4
Dimensions of automatic Sivelling table 55 x 55
Boring Stay:-
Diameter of the opening in boring stay 5 , 9
Internal diameter of the rotary bush mounted on ball bearings 3 , 93
Working Capacities:
Maximum Diameter bore with spindle 7, 87
Maximum Diameter bored with slide of facing head 43 5 / I6
Maximum Diameter turned or faced with slide of facing head:
- with square toolholder 43 5 / I6
- with Telescopic toolhoder 33
Spindle 39 , 37
Slide of facing head II , 02
Spindle holder head, vertical 5 I 3 / I 6
longitudinal of table, with boring stay
normal traverse: 63
extended traverse: 94 1 / 2
longitudinal of the table, without boring stay
normal traverse: 88 9 / I6
extended traverse: I20 I / I
transversal of the table
normal traverse: 63
extended traverse: 94 1 / 2
Distances:
from spindle to main rectangular table 2" 5 / 32 to 53" II / 32
from spindle to auxiliary top swiveling square table 0 to 48" 5 / 8
from spindle to table with automatic rotation 0 to 48 1 / 4
from facing head to boring stay
normal traverse I 08" 9 / 32
extended traverse I 39" 3 / 4
Speeds:
Spindle, I8 speeds r.p.m 8 , 5 to I 680
facing head, 9 speeds r.p.m. 8,5 to 335
automatic rotation of the swivelling table :
- for turning & rapid traverses, 3 sp. r.p.m. 5, 6 to 9 to I4,4
- for milling, 3 speeds r.p.m. 0 , 05 to 0,08 to 0,I
