| Machines » Thread / Worm Grinders » matrix 69 type 2 |
|
|
|
|
|
| Product Gallery : |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| Power |
: |
Electrical supply 385v / 3ph / 50hz |
|
| Location |
: |
Mumbai Warehouse,India |
|
|
 |
| Category |
: |
Thread / Worm Grinders |
|
|
|
|
|
| Type of Machine |
: |
Internal thread grinder |
|
|
|
|
|
|
|
|
|
|
| Specification : |
|
Max lead 50mm
Max diameter of bore 250mm
Min diameter of bore 25mm
Max diameter of component 330mm
Max length ground 200mm
Diameter of grinding wheel 13 to 102mm
Grinding wheel speeds low 13000 & 18000rpm
High 36000 & 42000rpm
Max number of passes 48
Max depth of in feed 1.27mm
Max side cut 2.54mm
Max helix angle 10 degrees R. H or L. H.
Work speeds low 6 to 52rpm
High80 & 105rpm
|
|
|
|
|
|
