Max. workpiece Ø 350 mm
Max. modulus f. hobbing cutters 8 mm
Max. addendum circle Ø 163 mm
L max. 230 mm (depending on cutter arbour Ø)
Cutter cutter Ø 22, 27, 32, 40 mm
Mounting taper MK5
Radial carriage travel 225 mm
Tangential carriage travel 170 mm
Axial carriage travel 250 mm
Max. cutter head pivoting angle +30°...-40°
#workpiece spindle outside Ø 350 mm
Workpiece spindle bore 150 mm
Counterholder travel 550 mm
Counterholder bore 150 mm
Speed - tool 120-400 rpm
Speed - tool spindle 1-40 rpm
Rapid speed on X axis 5,000 mm/min.
Rapid speed on Y axis 750 mm/min.
Rapid speed on Z axis 1,000 mm/min.
Autom. workpiece feeding unit
Cooling lubricant system
Oil mist extraction and filtering system
