Machines » Pressure Die Casting Machines (PDC) » h-660-d (working video attached)
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| Model |
: |
h-660-d (working video attached) |
|
|
|
|
|
| Dimensions |
: |
not available |
|
|
|
| Location |
: |
Mumbai Warehouse |
|
|
 |
| Category |
: |
Pressure Die Casting Machines (PDC) |
|
| Serial No |
: |
Not Available At The Moment |
|
|
|
| Type of Machine |
: |
pressure die casting |
|
|
|
|
|
|
|
|
|
|
| Specification : |
Centralised Automatic Die height adjustment Central Lubrication PLC control panel. Specifications :
Locking Force 660 ton
Injection force 65MP
Hydraulic Ejection Force 34Mp
Die Mounting Platen 1130x1190
Space between tie bars 720x780mm
Tie Bar diameter 150mm
Maximum Die Height 880 mm
Minimum Die Height 630mm
Injection plunger stroke 600mm
Free cycle time 6 seconds |
|
|
| Description : |
|
Machine Fully Rebuilt in 2000 Along
|
|
|
|
|
