Max. work piece diameter, mm 4000
Max. work piece height, mm 2000
Chuck diameter, mm 4000
Max. work piece weight, kg 50000
Max. travel of vertical supports, mm 1250
Max. cutting force on right support, kg 6300
Max. cutting force on left support, kg 5000
Supports possible work angle, deg. -15...+40
Chuck speed, rpm 0,52...48,7
Movement of vertical and horizontal feeds, mm/min 0,0059...470
Main electric motor power, kW 63
Machine overall dimensions, mm 5900 x 10100 x 7200
Height above floor level, mm 6000
Machine weight, kg app. 100000
