Rebuilt 2017 LS-150, 2-Axis CNC Gear Shaping Machine with Siemens 808D Advance System,
This Ex Aerospace machine has an Unique Advantage ,
Machine can be shown under power.
Full Guardings, Chip Conveyor , Hydrostatic Static Guide , Spur Guide ,

Machine Id: 1000 Serial No:
Model: LS 150 (January rebuilt 2017) Asking Price: onrequest
Make: Lorenz (Ex European Aerospace Company Machine) Country: Germany
Year: 2017 Weight: 0.0
Dimensions: Location:
Power:
Category: Gear Related Machines
Type of Machine: 2-Axis CNC Gear Shaping Machine and Siemens 808D Advance System
Specification

Rebuilt LS-150, 2-Axis CNC Gear Shaping Machine with Siemens 808D Advance System,

This Ex Aerospace machine Is Like New , Original system was Num 1030.



Brand : Lorenz
Model : LS-150 (CNC)
2-Axis CNC Gear Shaping Machine From European Aircraft Factory


Variable Speed Stroke
Cutter Positioning
Chip Conveyor
Coolant
Hydraulic Clamping

External Gears OD :- 150mmx 6 Module
Internal Gears Max. 100 + Cutter 0mm.
Length of Stroke 0 - 50mm
Adjustment of Stroke 0 - 70mm

No. of Double Stroke per Min. Approx. 355/375/400/1060/1120/1200
Radial Feed, Infinitely Variable 2.65 - 100 mm/min.
Shaping Feed 160 - 6500 mm/min.
Table Size 250 mm
Table Bore 100 mm
Distance Between Table and Shaper Head 265 mm (approx.)
Weight 6500 kg

Full Guardings, Chip Conveyor , Hydrostatic Static Guide , Spur Guide ,
