Gear Related Machines

Download Product PDF Enquiry / Quote / Interested Add this Favourite For Agents

Enlargeable Images :

Download Photo / Zip
Video
Machine Id: 1365 Serial No:
Model: OHA 12A Asking Price: onrequest
Make: TOS Country: Czech Republic
Year: 1969 Weight: 0.0
Dimensions: Location: Mumbai Warehouse,India
Power:
Category: Gear Related Machines
Type of Machine: Gear Shaping Machine
Specification

Max. diameter of gear wheel with external gears : 120 mm
Max. diameter of gear wheel with internal gears: 120 mm
Max. diameter of workpiece: 120 mm
Module: 0.5-4 mm
Gear width: 35 mm
Nominal tool diameter: 100mm
Table diameter: 125 mm
Engine power: 3/2.2 kW
Pump performance: 60 l / min-1
Machine dimensions: 1620 x 1690 x 1110 mm
Machine weight: 3 000 kg

Description
